EC220-F5

Overview

AC1200 Dual-Band Wi-Fi Router for Fast and Reliable Home Networking
The TP-Link EC220-F5 AC1200 Dual-Band Wi-Fi Router is designed to deliver fast, dependable wireless performance for modern homes. With dual-band Wi-Fi offering speeds of up to 300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band, it provides smooth connectivity for HD streaming, online gaming, video conferencing, and everyday browsing. Four external antennas help extend wireless coverage and improve signal stability throughout your home, while remote management support makes it an ideal solution for both consumers and internet service providers.

Description

The TP-Link EC220-F5 is a dual-band AC1200 wireless router built to provide stable, high-speed internet connectivity across multiple devices. Its four high-performance external antennas enhance wireless coverage, while support for TR-069, TR-098, Aginet Config, and Aginet ACS enables simplified remote management for ISPs. Easy installation through the TP-Link Tether app, parental controls, and Multi-SSID support make this router a practical choice for homes and managed network environments. Part Number / SKU: EC220-F5.

Features

High-Speed Dual-Band Wireless Performance
Powered by Wireless AC technology, the EC220-F5 delivers significantly faster wireless speeds than traditional Wireless N routers. The dual-band design allows users to separate bandwidth-intensive applications from everyday internet use, helping maintain a smooth and responsive network experience.

Wireless speeds include:

• Up to 867 Mbps on the 5 GHz band
• Up to 300 Mbps on the 2.4 GHz band

This combination is well suited for:

• HD and 4K video streaming
• Online gaming
• Video conferencing
• Large file downloads
• Simultaneous connections for multiple devices

Extended Wi-Fi Coverage Throughout Your Home
The router features four strategically positioned external antennas that improve signal strength and receiving sensitivity. This antenna design helps reduce dead zones while delivering more reliable wireless coverage across larger living spaces.

Benefits include:

• Improved wireless stability
• Wider Wi-Fi coverage
• Better performance for connected devices
• Reliable connections in multiple rooms

Parental Controls for Safer Internet Access
Built-in parental controls make it simple to manage internet usage for family members or workplace users. Administrators can restrict access to selected websites using keyword-based filtering and create a safer online environment.

Key advantages:

• Restrict inappropriate websites
• Create keyword-based blacklists
• Manage internet access with ease

Multiple Wireless Networks with Multi-SSID
Support for Multi-SSID allows separate wireless networks to be created for different applications or user groups. This functionality is particularly useful for service providers deploying services such as IPTV alongside standard internet access.

Simple Setup Using the TP-Link Tether App
The free TP-Link Tether app for Android and iOS simplifies router installation and ongoing management. Users can configure settings, monitor their network, and make adjustments directly from a smartphone or tablet.

The app allows you to:

• Complete initial setup quickly
• Manage wireless settings
• Monitor connected devices
• Update network preferences conveniently

Built for ISP Remote Management
The TP-Link EC220-F5 includes support for industry-standard remote management protocols, helping internet service providers deploy and maintain customer equipment efficiently without requiring on-site visits.

Supported management technologies:

• TR-069
• TR-098
• Aginet Config
• Aginet ACS

These technologies allow ISPs to:

• Remotely configure customer routers
• Preserve custom settings after factory resets
• Reduce maintenance costs
• Simplify large-scale device management

Network Connectivity
The router includes:

• 1 x 10/100 Mbps WAN port
• 4 x 10/100 Mbps LAN ports
• 4 external high-gain antennas
• Dual-band AC1200 Wi-Fi

Why Choose the TP-Link EC220-F5
Whether you need dependable Wi-Fi for a busy household or an easily managed router for ISP deployment, the TP-Link EC220-F5 delivers strong wireless performance, broad coverage, and straightforward management. Its dual-band connectivity, robust antenna design, remote management capabilities, and user-friendly mobile app make it an excellent networking solution for everyday internet use.

Specifications

©2026 Respective owners and brand holders. This table has been carefully researched and generated by ComXpert International CC (//www.comx-computers.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	EC220-F5
HARDWARE FEATURES
Interface	1 x 10/100 Mbps WAN Port
	4 x 10/100 Mbps LAN Ports
External Power Supply	9 V 0.85 A
Dimensions ( W x D x H )	9.1 x 5.7 x 1.5 in
	(229.9 x 144.2 x 36.9 mm)
Antenna	4 External Antennas
WIRELESS FEATURES
Wireless Standards	IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency	2.4 GHz and 5 GHz
Signal Rate	2.4 GHz: 300 Mbps
	5 GHz: 867 Mbps
Transmit Power	CE: <20 dBm(2.4 GHz), <23 dBm (5 GHz)
Wireless Functions	Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Schedule, Wireless Statistics, Access Point mode
Wireless Security	WPA/WPA2 encryptions
SOFTWARE FEATURES
Quality of Service	QoS by Device
WAN Type	Dynamic IP, Static IP, PPPoE, PPTP, L2TP
Management	Local management: WebGUI, Tether app
	Remote management: TR-069, TR-181, TR-111, TR-143, Aginet ACS
DHCP	Server, Client, DHCP Client List, Address Reservation
Port Forwarding	Vritual Server, Port Triggering, DMZ, UPnP
VPN Pass-Through	PPTP, L2TP, IPSec
Access Control	Parental Controls, Local Management Control, Host List, White List, Black List
Firewall Security	DoS, SPI Firewall, IP Address Filter, IP and MAC Address Binding
Protocols	Supports IPv4 and IPv6
OTHERS
Package Contents	Wi-Fi Router EC220-F5
	Power Adapter
	RJ45 Ethernet Cable
	Quick Installation Guide
Requirements	Microsoft Windows 98SE / NT / 2000 / XP / Vista / 7 / 8 / 8.1 / 10, MAC OS, NetWare, UNIX or Linux
	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other Java-enabled browser
	Cable or DSL Modem (if needed)
	Subscription with an internet service provider (for internet access)
Certifications	CE, RoHS
Environment	Operating Temperature: 0degreesC-40degreesC (32degreesF-104degreesF)
	Storage Temperature: -40degreesC-60degreesC (-40degreesF-140degreesF)
	Operating Humidity: 10%-90% non-condensing
	Storage Humidity: 5%-90% non-condensing
